| Model |
OT17TA |
OT17TB |
| Cabinet Color |
Black |
| Display Area |
337.92 * 270.336 mm |
| Optimal Resolution |
1280 * 1024 |
| Brightness |
350 cd/m² (typ) |
| Contrast Ratio |
1000:1 (typ) |
| Response Time |
5 ms (typ) |
| LCD Viewing Angle(L/R/U/D) |
85 / 85 / 80 / 80 |
| Input Video signal connector |
D-Sub 15 pins |
D-Sub& DVI |
| Power consumption |
30W |
| Input Frequency |
Horizontal: 31.5-60.2 kHz Vertical : 56.3Hz-75Hz |
| Power supply |
DC 12V +/- 10% |
| Tempurature |
Operating : 0℃~40℃ Storage : -10℃~50℃ |
| Humidity |
Operating : 20%~80% Storage : 10%~90% |
| Weight |
5.86kg (Net) |
| Physical Dimension |
399.2 (W ) * 381.5 (H) * 200 (D) mm |
| Approvals |
CE, FCC, BSMI |
| Touch |
5W wires Taiwan Touch |
| Optional item |
| Cabinet Color |
White |
| MSR |
3 tracks |
| 2nd display |
7" / 8.4" / 10.4" Customer Display |
| Customer display |
VFD |
